Manor

Atelier Unfinished Versailles Panel

Manor

Atelier Unfinished Versailles Panel

This product has been discontinued

A luxurious engineered French Oak product, best suited for flooring. These 800 by 800mm parquetry panels are reminiscent of the style of flooring you would find in old French castles, such as the palace of Versailles. Unfinished means this product is supplied raw, without any colour or finishing product applied. This 19mm thick panel can be used in conjunction with other 19mm Manor products, such as 19mm thick Atelier Unfinished planks.

Atelier is a subrange of Manor which includes products with an aged, character look and texture you can see and feel. Products from this range have a wear layer of rustic grade French Oak, with surface effects including brushing, handscraping and sunken knots and cracks.

About the Brand

Manor Collection is Forté's own brand; a luxurious collection of PEFC certified engineered French Oak timber flooring and wall coverings which spans several sub-ranges. Manor products are known for their distinctive aged appearance, with each range having its own distinctive look. Each look is a result of the grade of timber together with different techniques used on the surface, such as various levels of wire brushing, different methods of filling knots and cracks, and special hand crafted effects. What really sets Manor products apart is the spectacular raw-look finishes and an incredible depth of colour throughout the boards, achieved through specialist techniques which are almost impossible to replicate.
  • Code: MVU19
  • Dimensions: 19mm H x 800mm W x 800mm L
  • Availability: Custom Order | Lead Time: 16 weeks | MOQ: 80m²
  • Application: Flooring
  • Price Indication: $$$$$
Classification
Collection Manor
Product Name Versailles Unfinished
Product Code MVU19
Product Type Engineered Plank
Usage
Suitable Projects Residential & Commercial
Suitable Applications Flooring
Underfloor Heating Compatible with hydronic type - please enquire for others
Wet Areas Contact us for information
Dimensions & Construction
Thickness 19mm
Width 800mm
Length 800mm
Re-sands 4-5 times (approx)
Wear Layer 6mm Solid French Oak
Core Cross-directional plywood
Backing French Oak strips
Characteristics
Colour Process -
Wood Species French Oak
Wood Grade Feature
Surface Texture Lightly brushed & handscraped
Status Unfinished
Finish Type -
Edge Style Bevelled 4 sides
Accreditations
Formaldehyde Emission EN717-1 E1
Certification
PEFC Certified Yes
Warranty
Residential 25 Years
Commercial 5 Years
Installation
Installation Method Direct stick
Suitable Substrates Plywood, particle board, concrete
Joint Profile Tongue & groove

At Forté we care about the environment - click here to find out what we are doing to help.

Technical Specs
Slip Resistance AS/NZS 4586 - Dry Floor Friction Test (FFT) Classification F - Mean COF 0.85 [Moderate to very low]
Slip Resistance AS/NZS 4586 - Wet Pendulum Test (PTV) Classification X - 42 BPN [Moderate risk]
Reaction to Fire (Flooring) ISO 9239-1 Critical Radiant Flux 2.2 kw/m²
Reaction to Fire (Walls & Ceilings) ISO 9705 Group 3 (Fire shield can be applied to meet Group 1-S)
